Take your drainage to the next level with the ACO Brickslot 100 – the perfect outdoor solution for maximum runoff control and water management!

Brickslot is a discrete drainage solution for use with brick or stone pavers up to 2.48” (63 mm) deep. The 0.47” (12 mm) slot blends in with the paving joints giving an aesthetic solution.

Brick pavers fit directly against the slot. For light duty pedestrian applications, pavers can be set on sand. For heavier duty projects, pavers should be set on concrete. Designed for 3.15” (80 mm) pavers.

Brickslot is also offered in a single or twinslot option as well as ADA-compliant. The low profile drainage solution is perfect for landmarks, resorts, monuments, memorials, and any pedestrian walkway where a discreet barrier

The slot is a smooth, easy to clean opening that allows continuous water flow into the channel. Heel-resistant Brickslot offers an offset 0.31” (8 mm) flared slot opening to 0.87” (22 mm) throat for increased drainage capacity.

Brickslot fits directly into K100 and K200 channel grate recesses, both galvanized and stainless options. Half meter sections are available as well as half meter access units provide entry to channel or catch basin for maintenance.
